| BATTERY / 2000 TM |
ISO-9002/UL/CE/TUV certified |
|
|
| 2M-1250HC |
HIGH RATE SERIES |
12V-5.0AH |
|
|
| |
|
| |
|
SPECIFICATIONS |
|
|
|
|
|
|
|
| |
|
|
Nominal Voltage |
12 |
|
|
| |
|
|
Terminal Type |
187// 250
faston |
|
|
| |
|
|
Max. Discharge Current |
1.26 Amps |
|
|
| |
|
|
Internal Resistance |
30 Mili. Ohms |
|
|
| |
|
|
Max. Charge Current |
|
1.26 Amps |
|
|
|
| |
|
|
Weight |
1.95 kg (4.30
lbs.) |
|
|
| |
|
|
Dimensions |
Length |
90 mm (3.54") |
|
|
|
| |
|
|
Width |
70 mm (2.76") |
|
|
|
| |
|
|
Height |
101 mm (3.74") |
|
|
|
| |
|
|
Total Height |
107 mm (3.98") |
|
|
|
| |
|
|
Plates |
Separator |
|
|
| |
|
|
Lead Calcium alloy |
Micro porus |
|
|
| |
|
|
Self Discharge @ 77*F (25*C) |
|
|
| |
|
|
Capacity after 3 months
storage |
91% |
|
|
| |
|
|
Capacity after 6 months
storage |
82% |
|
|
| |
|
|
Capacity after 12 months
storage |
64% |
|
|
| |
|
|
Capacity affected by temperature (20 hr. rate) |
|
|
| |
Product Features |
|
|
|
|
|
104*F (40*C) |
|
102% |
|
|
| |
|
|
|
|
77*F (25*C) |
|
100% |
|
|
| |
Maintenance
Free. |
|
|
|
32*F (0*C) |
|
85% |
|
|
| |
Sealed Construction makes
it spill proof. |
|
|
|
|
58*F (15*C) |
|
65% |
|
|
| |
Vent system automatically
opens and reseals. |
Capacity @ 77*F (25*C) |
|
|
| |
Excels at standby or
cycle application. |
|
5.0Ah @ 20 hour rate |
|
|
| |
Built with heavy duty
grids and virgin lead. |
|
4.75Ah @ 10 hour rate |
|
|
| |
Rugged ABS housing for
easy handling. |
|
4.25Ah @ 5 hour rate |
|
|
| |
Battery will operate in
any position. |
|
|
3.00Ah @ 1 hour rate |
|
|
| |
Battery is 100% memory free |
|
|
Discharge |
(-40*F)
(-40*C) to (+140*F) (60*C) |
|
|
| |
|
Charge |
(-4*F) (-20*C) to (+122*F) (50*C) |
|
|
| |
We recommend a constant voltage charge |
Recommended |
(68*F) (20*C)
to (77*F) (25*C) |
|
|
| |
Do not charge in upside down position. |
Charging (constant voltage) |
|
|
| |
|
|
Cycle use |
14.4
- 15.0 volts @ (77*F) (25*C) |
|
|
| |
|
|
Float use |
13.5
- 13.8 volts @ (77*F) (25*C) |
|
|
| |
|
|
Storage |
6 months @
68*F (20*C) |
|
|
| DISCHARGE SPECIFICATIONS |
|
|
|
Constant power rating, Watts per battery @77*F (25*C) in minutes |
|
|
|
|
| Final VPC |
5 |
10 |
15 |
20 |
30 |
40 |
45 |
50 |
60 |
90 |
|
|
|
|
| |
1.60 |
798 |
595 |
471 |
395 |
304 |
249 |
231 |
212 |
187 |
137 |
|
|
|
|
|
|
|
| |
1.67 |
749 |
569 |
460 |
388 |
298 |
244 |
225 |
208 |
183 |
134 |
|
|
|
|
|
|
|
| |
1.70 |
723 |
557 |
452 |
382 |
295 |
242 |
224 |
207 |
182 |
133 |
|
|
|
|
|
|
|
| |
1.75 |
679 |
518 |
437 |
374 |
288 |
238 |
221 |
205 |
180 |
132 |
|
|
|
|
|
|
|
| Constant current rating, Amps @77*F (25*C) in hours |
|
|
| |
|
1 |
2 |
3 |
4 |
5 |
6 |
8 |
10 |
12 |
24 |
|
|
|
|
|
|
|
| |
1.75 |
15.50 |
8.99 |
6.50 |
5.09 |
4.23 |
3.58 |
2.82 |
2.38 |
1.95 |
1.08 |
|
|
|
|
|
|
|
| |
1.80 |
14.70 |
8.67 |
6.28 |
4.88 |
4.01 |
3.47 |
2.71 |
2.28 |
1.95 |
1.04 |
|
|
|
|
|
|
|
| |
1.85 |
13.80 |
8.23 |
5.96 |
4.66 |
3.90 |
3.36 |
2.60 |
2.17 |
1.84 |
0.99 |
|
|
|
|
|
|
|
| |
1.90 |
12.40 |
7.58 |
5.53 |
4.33 |
3.68 |
3.14 |
2.49 |
2.06 |
1.73 |
0.94 |
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
